CBB-100N IP55 centrifugal fan

Radial fans suitable for very long ducts in various process and air handling applications.

B2B clients will see their prices after logging in

41 431,00 CZK excl. VAT

50 131,51 CZK incl. VAT

Availability: on request [20.8.2025, 04:10] Update

Add to project

Goods cannot be ordered online.
Contact our sales specialists
or visit our branches.

Add to project

Insert into the design HVAC program

Insert into EasyVent

Product code: SP260100150

EAN: 8413893156402

Manufacturer: S&P SISTEMAS DE VENTILACIÓN, S.L.U. Read moreRead less

S&P SISTEMAS DE VENTILACIÓN, S.L.U.
Llevant, 4
Polígono Industrial Llevant
08150 Parets del Vallès
Barcelona – Spain
consultas[zav]solerpalau[teč]com
www.solerpalau.com/en-en/home

Product description

Cabinet

The radial fan housing is cast in Al alloy, coated with grey epoxy paint).

Iris wheel

is radial, cast in Al alloy.

Motor

is asynchronous with short armature, grease-filled ball bearings for life. Motor out of air stream. Protection IP55, insulation class F (models CSB, CST and CBT-40 protection IP44, insulation class B).

Speed control

Inquire about the possibility and conditions of use of VFVN frequency converters.

Clamping box

is located on the motor.

Mounting

is carried out on the mounting base. All types (except CSB and CST) can be rotated by 45° to achieve the desired discharge direction. At the same time, it is possible to mount the motor on both the right and the left without having to change the direction of the discharge port.

Instructions

The fans are suitable by their design for very long ducts in various process and air handling applications. They are not suitable for the extraction of wood dust and grit, or other flammable or explosive mixtures.

Caution

Alternatively, motors are supplied with a thermal fuse in the winding. In this case, the wiring diagram supplied with the fan in the documentation must be used. The thermal fuse must always be plugged in, otherwise the motor is not eligible for warranty repair.

Full description

Safety regulations

Adherence to these instructions should not pose any safety, health or environmental risks in accordance with EC directives (CE marked). The same applies to other products used in the device or during installation. Consider the following warnings:

• Observe the safety instructions to prevent damage to the device or personal injury.
• The technical information in this manual must not be changed.
• It is forbidden to interfere with the motor of the device.
• In order for the device to comply with EC directives, the device must be connected to the mains in accordance with the applicable regulations.
• The device must be installed in such a way that under normal operating conditions it cannot come into contact with any moving part and / or live part.
• The device complies with the applicable regulations for the operation of electrical equipment.
• Always disconnect the device from the power supply before carrying out any work on it.
• Appropriate tools must be used when handling or maintaining the device.
• The device must only be used for the purposes for which it is intended.
• This appliance is not intended for use by children under 8 years of age and persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a responsible person. The user must ensure that children do not play with the device. Cleaning and maintenance of the appliance must not be carried out by children without supervision.

Downloads

Technical sheets, manuals and declarations

Datasheet .pdf (293.40 kB)

Operating Instructions .pdf (202.82 kB)

Declaration of conformity .pdf (360.22 kB)

CAD files

2D .dwg (239.47 kB)

3D .dwg (1.25 MB)
